SME Surface Mount Electrolytic Capacitors
| Part Number | Body Size |
Tape Width |
Tape Pitch |
Quantity 13" Reel |
| 3mm-SME-PL | 3mm | 12mm | 8mm | 2,000 |
| 4mm-SME-PL | 4mm | 12mm | 8mm | 2,000 |
| 5mm-SME-PL | 5mm | 12mm | 12mm | 1,000 |
| 6.3mm-SME-PL | 6.3mm | 16mm | 12mm | 1,000 |
| 8mm-SME-PL | 8mm | 16mm | 12mm | 1,000 |
| 10mm-SME-PL | 10mm | 24mm | 16mm | 500 |
- Surface mount electrolytic capacitors come standard on 13" reels.
- Components are measured by the diameter of the electrolytic can.
- PL = Plastic carrier tape.
