Jerry-Rig Universal Work Positioner

Jerry-Rig
Universal Work Positioner

	Ergonomic design enables 360 degree rotation in all directions Clamps to a workbench for vertical or horizontal positioning Quick locking and unlocking with large, comfortable handle Hold a variety of fixtures and vises that slide in and out of the base Clamp and positioner are heavy duty aluminum castings painted blue Fits all Pana-Vise™ holding fixtures
Illustrated is the Jerry-Rig with a 'U' style, spring-loaded PCB vise, Part Number JR-UV1	Base unit consists of table clamp and work positioner, Part Number is JR-100E for this assembly. Click here to view the isometric drawing of this. The table below lists complete Jerry-Rig fixture assemblies or you can purchase the Jerry-Rig components separately as listed. They will all fit into the JR-100E.

Click image to enlarge Jerry-Rig with MF-8 Mini-Flip PCB fixture shown in vertical position (Part Number JR-MF8)	Click image to enlarge Jerry-Rig with large peg vise for holding larger, odd shaped boards or assemblies. Two moveable plates with tapped holes on 1/2" centers and four pegs make this very versatile. (Part Number JR-PV2)	Click image to enlarge Jerry-Rig with two jaw vise for holding mechanical assemblies. Opens to 9.5 inches with rubberized jaws. (Part Number JR-JV1)
Click image to enlarge Jerry-Rig with small peg vise for very small, odd shaped boards or assemblies, under 2" x 2". (Part Number JR-PV1)	Click image to enlarge Jerry-Rig with MF-8 Mini-Flip PCB fixture shown in vertical but rotated forward position. (Part Number JR-MF8)	Click image to enlarge Jerry-Rig with freestanding base and U style PCB Fixture. PCB capacity of 11" in width; rails are 6" high. (Part Number JR-TT-UV1).
Click image to enlarge Jerry-Rig with large peg vise for round boards and table legs. (Part Number JR-TT-PV2).

Jerry-Rig with two jaw vise	JR-JV1
Jerry-Rig with MF-8 PCB holder	JR-MF8
Jerry-Rig with MF-12 PCB holder	JR-MF12
Jerry-Rig with ?U? shaped PCB holder	JR-UV1
Jerry-Rig with large peg vise	JR-PV2
Jerry-Rig with small peg vise	JR-PV1
Jerry-Rig with ?U? shaped PCB holder and four legs for table mounting	JR-TT-UV1
Jerry-Rig with clamp	JR-100E
Jerry-Rig with table legs	JR-100T
Jerry-Rig with large peg vise for round boards and table legs	JR-TT-PV2
MF-8 PCB Holder	JMF-8
MF-12 PCB Holder	JMF-12
Two jaw vise	JV1
?U? shaped PCB holder	UV1
Large peg vise for small round boards	PV2
Legs set for table top use, no clamp	JR-LS
